S-Chassis VQ Swap Information
M O T O R S E T
The best option is a complete pull out from any RWD VQ car. 350z/G35 are the most common. If you are piecing parts together, make sure the parts are compatible.
- Complete Engine
- Complete Transmission
- Complete Engine Harness + ECU
- Accelerator Pedal w/ wiring
- OBD2 Plug w/ wiring
M O U N T S
OEM VQ mounts do not work with the S-Chassis. You will need to fabricate custom mounts or choose one of the available options. We offer bolt in mounts for VQ to S-Chassis
Our swap mounts will securely allow a VQ to be mounted in your S Chassis. The mounts will replace VQ motor and transmission mounts.
*NOTE*: mount color will vary
Includes
L + R motor mount
Transmission mount
80A hardness isolator
Necessary hardware
FREE SHIPPING!
Features
Made in the USA
100% TIG welded
SAE 1045 steel
Clears sway bar
Hexagon windows
RHD mounts made to order (2-3 week wait time)
Engine Fitment
VQ35DE 03-06
VQ35HR 07-08
VQ25HR 06+
VQ37VHR 09+
Transmission Fitment
6MT DE through VHR
Chassis Fitment
S13
S14
S15
*NOTE* Hood clearance modification may be needed. HR starter motors will need clearance modifications. Exhaust manifold will need slight modification to clear steering shaft
*NOTE* RHD mounts are made to order.
W I R I N G | E C U
OEM VQ harness and ECU can be used with the S-Chassis, however, the ECU must be flashed in order to work correctly. The ECU must have NATS (anti-theft) disabled in order to start in a S-Chassis. The easiest way is to use Uprev Osiris. The VQ harness will need to be wired in to your S-Chassis. We provide a wiring and ECU service.
D R I V E L I N E
The driveline must be custom. There are many retailers that provide them. We will be releasing our driveshaft on the site very soon.
1 PC Aluminum driveshaft using Spicer drivetrain parts. All drivelines take 3 business days to build and ship within 1 Business day of completion.
F u e l S y s t e m
A new fuel system will be needed to make use of the S-Chassis return-style system. There are many different ways of going about this. We made it easy with our HEXA fuel system.
V2 Shipping Now with radium regulator.
allow 1 week build time if backordered.
Our VQ swap fuel system will allow you to run the stock S Chassis fuel setup without modifying your motor. Compatible with DE, HR, and VHR fuel rails. Please specify when ordering.
Includes
Radium Fuel Regulator
Fuel filter
Fuel lines
Hardware
Instructions
Features
40µm billet aluminum fuel filter
Ethanol Safe
billet fuel regulator
black anodized finish
6AN hardware
Compatible with DE, HR, and VHR fuel rails
plug and play
*NOTE* Hard lines must be bent out of the way of the exhaust manifold
Note2: We are on a newer version than pictured
P o w e r S t e e r i n g
The VQ pump is compatible with the S-Chassis steering rack. The VQ comes with a cooler directly from the factory. It is a must have for this swap. VQ and S-Chassis OEM parts can be retrofitted to work. We offer a bolt in solution for your power steering needs.
The Hexa Garage power steering kit will keep your fluid cool under the most extreme conditions.
Please allow 1 week to build if backordered.
Includes:
High pressure line
Low pressure lines
Power steering fluid cooler
Power steering fluid reservoir
Brackets
Hardware
-6 AN Rack Fittings
Features:
Therdyn aluminum fluid cooler
Internally baffled fluid reservoir
High quality AN fittings
SAE J2076 standards
Gloss finish
Made in the USA
Engine Fitment
VQ35DE 03-06
VQ35HR 07-08
VQ25HR 06+
VQ37VHR 09+
Chassis Fitment
S13
S14
S15
NOTE: We are on a newer version than pictured.
C o o l i n g s y s t e m
The VQ likes to stay cool in a S-Chassis. The easiest way is to use a KA24DE radiator. It is enough to keep the VQ under hard driving. Heater hoses can be routed to retain OEM heat controls. We offer a cooling hose kit that includes heater and radiator hoses.
The Hexa VQ coolant hose kit is a bolt on solution for coolant routing. It allows you to use OEM/aftermarket KA24DE Radiator.
Includes
Upper Hose
Lower Hose
Crossover Tube
Hardware
Features
Mulit-layer reinforced silicone hose
Stainless steel hose clamps
Aluminum crossover tube
Engine Fitment
VQ35DE
Radiator Fitment
KA24DE
*FREE SHIPPING*
I n s t r u m e n t C l u s t e r
You can use OEM S-Chassis cluster, VQ cluster, CAN BUS cluster, or individual gauges. Dakota converters will be needed to keep the S-Chassis cluster. The VQ cluster is available in our store, ready to wire in.
